| الاسم التجاري: | DLX |
| رقم الموديل: | انكونيل 718 |
| موك: | 5 |
| شروط الدفع: | خطاب الاعتماد، تي/تي، ويسترن يونيون |
| القدرة على العرض: | 500 طن شهريا |
Inconel Alloy 718 is a precipitation hardenable nickel-based alloy designed to display exceptionally high yield, tensile and creep-rupture properties at temperatures up to 1300°F. The sluggish age-hardening response of alloy 718 permits annealing and welding without spontaneous hardening during heating and cooling. This alloy has excellent weldability when compared to the nickel-base superalloys hardened by aluminum and titanium. This alloy has been used for jet engine and high-speed airframe parts such as wheels, buckets, spacers, and high temperature bolts and fasteners.
| Element | Limiting Chemical Composition (%) |
| Nickel (plus Cobalt) | 50%-55% |
| Chromium | 17%-21% |
| Niobium (plus Tantalum) | 4.75%-5.50% |
| Molybdenum | 2.80%-3.30% |
| Titanium | 0.65%-1.15% |
| Aluminum | 0.20%-0.80% |
| Cobalt | 1% max |
| Carbon | 0.08% max |
| Manganese | 0.35% max |
| Silicon | 0.35% max |
| Phosphorus | 0.015% max |
| Sulfur | 0.015% max |
| Boron | 0.006% max |
| Copper | 0.30% max |
| Iron | Balance* |
Some typical applications are:
| AMS Number | Alloy | Type | UNS | Cross Ref. Spec | Misc./Shape | |
|---|---|---|---|---|---|---|
| AMS 5590 | Inconel 718 | Nickel | N07718 | - | Tubing | |
| AMS 5596 Foil | Inconel 718 | Nickel | N07718 | - | Foil | |
| AMS 5596 Plate | Inconel 718 | Nickel | N07718 | - | Plate | |
| AMS 5596 Sheet | Inconel 718 | Nickel | N07718 | - | Sheet | |
| AMS 5596 Strip | Inconel 718 | Nickel | N07718 | - | Strip | |
| AMS 5597 Plate | Inconel 718 | Nickel | N07718 | - | Plate | |
| AMS 5597 Sheet | Inconel 718 | Nickel | N07718 | - | Sheet | |
| AMS 5597 Strip | Inconel 718 | Nickel | N07718 | - | Strip | |
| AMS 5662 Bar | Inconel 718 | Nickel | N07718 | - | Bar | |
| AMS 5662 Custom Tube | Inconel 718 | Nickel | N07718 | - | Custom Tube | |
| AMS 5662 Ring | Inconel 718 | Nickel | N07718 | - | Ring | |
| AMS 5663 Bar | Inconel 718 | Nickel | N07718 | - | Bar | |
| AMS 5663 Custom Tube | Inconel 718 | Nickel | N07718 | - | Custom Tube | |
| AMS 5663 Ring | Inconel 718 | Nickel | N07718 | - | Ring | |
| AMS 5664 Bar | Inconel 718 | Nickel | N07718 | - | Bar | |
| AMS 5664 Custom Tube | Inconel 718 | Nickel | N07718 | - | Custom Tube | |
| AMS 5664 Ring | Inconel 718 | Nickel | N07718 | - | Ring | |
| AMS 5832 | Inconel 718 | Nickel | N07718 | - | Wire | |
| AMS 5962 Bar | Inconel 718 | Nickel | N07718 | - | Bar | |
| AMS 5962 Wire | Inconel 718 | Nickel | N07718 | - | Wire | |
